Chapter 2
OPERATIONS
2.7
SOFT KEY OPERATION
2-28
Soft key 3: True Relative
Sets whether to display parallel cursors in true bearing mode or relative bearing
mode.
"True": "Parallel Cursor" is displayed in true bearing mode.
"Relative": "Parallel Cursor" is displayed in relative bearing mode.
Reference:
Bearing signal input is required to display true motion.
Soft key 4: Bearing Interval
When "Parallel Cursor" of the soft key menu is selected, "BRG Operation" of the
soft key display is color-inverted.
When "Bearing" is displayed above the soft key 4
Turn the [MULTI] control to change the direction of "Parallel Cursor".
Press the soft key 4 to determine the bearing setting of "Parallel Cursor" for
length setting.
Length setting can be operated.
Press the [MULTI] control or the [CLEAR] key when you want to set the
bearing only. Bearing is set and operation state ends.
When "Interval" is displayed above the soft key 4
Turn the [MULTI] control to change the length of "Parallel Cursor".
Press the [MULTI] control, the soft key 4 or the [CLEAR] key to determine
the length setting of "Parallel Cursor". Length is set and operation state ends.
Reference:
When "Parallel Cursor" is not selected on the soft key menu, press the soft key 4 to
activate the Parallel Cursor function.
To Next Page
