Chapter 7
SPECIFICATIONS
7.3
DISPLAY UNIT
7-11
7
INSTRUCTION MANUAL
7.3 DISPLAY UNIT
7.3.1 INTEGRATED DISPLAY UNIT (NCD-2182)
(1) Structure Desk Top Integrated Type (LCD Monitor Unit/Keyboard
Unit/Processor Unit Integrated Structure)
Vertical installation only desk top integrated type
(2
)Di
mensions
Desktop installation Height 310mm× Width 328mm × Depth 130.5mm
Flush-mounting Height 290mm × Width 297mm × Depth 120mm
(3)
Mass Approx. 5kg
(4) Tune Method MANUAL/AUTO (Bar-graph indication)
(5) STC (SEA) MANUAL/AUTO
(6) FTC (RAIN) MANUAL/AUTO
(7)Radar Interference Rejection
Built-in (The effect can be adjusted by three stages.)
(8) Bearing Marker 360° in 5° digit
(9) Heading Line Electronic
(10) Off Center Within 66% of the radius of PPI
(Not available at the maximum range)
Transition of the radar trails is possible during Off Center
mode.
(11)
True Motion Unit Built-in (Not available at the maximum range)
(12) True Motion Reset Position
66% of radius of any range
(13) Radar trail indication True motion mode: Only true motion trails
Relative motion mode: Only relative motion trails
Trail time length: 15 sec to 15 min/Continuous
30 sec to 30 min/Continuous
1 min to 1 hr/Continuous
30 min to 12 hr/Continuous
Arbitrary trail time length can be displayed at any time.
Possible to display time series trail and continuous trail
by color classification.
Not possible to select true motion trails or relative motion
trails.
* When switching to true/relative trails, the radar trails
are cleared.
Transition of the trails is possible during Off Center
mode (Relative motion). (Scroll)
When the bearing mode is switched (RM (T), TM)
