JRC JMA-3300 Series User Manual

Chapter 7

SPECIFICATIONS
7.2

SCANNER
7-7
7
INSTRUCTION MANUAL
7.2.4 NKE-2063$+6$+6
(1) Dimensions Height 419.5mmSwing Circle 1220mm
(2) Mass Approx. 21kg
(3) Polarization Horizontal Polarization
(4) Directional Characteristic
Horizontal Beam Width (-3dB):
2°
Vertical Beam Width (-3dB):
30°
Sidelobe Level: -23dB or less (less than ±10° from the main lobe)
-26dB or less (±10° or more from the main lobe)
(5) Rotation
(6) Peak Power
Approx.27rpm(NKE-2063$)
(16/17.4/19/20.6/22.2/23.8/25.4/27rpm can beset)
Approx. 48rpm(NKE-2063+6$+6)
(27/36/48rpm can beset)
6 kW
(7) Transmitting Frequency 9410 r30MHz
(8) Transmitting Tube Magnetron [MSF1422B]
(9) Pulse width/Repetition Frequency (Bandwidth)
SP1: 0.08Ps/4000Hz, SP2: 0.08Ps/2250Hz, SP3: 0.13Ps/1700Hz
MP1: 0.25Ps/1700 Hz, MP2: 0.5Ps/1200 Hz
/3ȝV+]/3ȝV+]
0.125NM 0.08Ps/4000Hz (SP1)
0.25NM 0.08Ps/4000Hz (SP1)
0.5NM 0.08Ps/4000Hz (SP1) 0.25Ps/1700Hz (MP1)
0.75NM 0.08Ps/2250Hz (SP2) 0.25Ps/1700Hz (MP1)
1.5NM 0.08Ps/2250Hz (SP2) 0.25Ps/1700Hz (MP1) ȝV+]03
3NM 0.13Ps/1700Hz (SP3) 0.25Ps/1700Hz (MP1) ȝV+]03
6NM 0.5Ps/1200Hz (MP2) ȝV+]/3 ȝV+]/3
12NM 0.5Ps/1200Hz (MP2) ȝV+]/3 ȝV+]/3
24NM 1.0Ps/650Hz (LP2)
48NM 1.0Ps/650Hz (LP2)
72NM 1.0Ps/650Hz (LP2)
(10) Duplexer Circulator + Diode Limiter
(11) Front End Module MIC
