Chapter 2
OPERATIONS
2.11
MARKER SETTING
2-88
Setting the EBL bearing fix mode
Reference:
Course data input is required for Bearing Fix setting.
While this function is set to Angle Fix , an EBL is fixed to the preset bearing. For
example, if the true bearing 020° is preset, the EBL is fixed to the true bearing 020° even
when the own ship turns.
While the function is set to Screen Fix , the EBL is fixed on the radar display.
1 Open EBL1 EBL2 - Bearing Fix .
"Bearing Fix" menu appears.
Angle Fix
: EBL bearing is fixed to the preset value.
Screen Fix : EBL bearing is fixed on the radar display.
2.11.2 SETTING OPERATIONS FOR PARALLEL CURSORS
Parallel cursors can be set.
"Parallel Cursor" operations
1 Open Marker - Parallel Cursor .
"Parallel Cursor" menu appears.
