Chapter 2
OPERATIONS
2.7
SOFT KEY OPERATION
2-24
Soft key 4: BRG Operation
When "EBL1" or "EBL2" of the soft key menu is selected, "BRG Operation" of
the soft key display is color-inverted.
Turn the [MULTI] control to change the direction of "EBL1"/"EBL2".
To determine the setting of "EBL1"/"EBL2", press one of the followings:
the [MULTI] control, the soft key 4 or the [CLEAR] key.
The bearing is set and operation state ends.
Reference:
When "EBL1"/"EBL2" is not selected on the soft key menu, press the soft key 4 to activate
the EBL function.
EBL Bearing Display
The bearing values of EBL1 and EBL2 displayed on the PPI are indicated at the radar
display.
Even if EBL1 and EBL2 are not displayed, the bearing values are displayed.
2.7.2 MEASURING RANGE TO TARGET (VRM)
Measures the range with VRM (Variable Range Marker).
1 Select VRM1 VRM2 on the soft key menu.
When "VRM1" is selected, the soft key menu is turned off and "DIST Operation" of
the soft key display is color-inverted.
"VRM1" is activated.
Select "VRM1" and press the control.
To Next Page
