Chapter 7
SPECIFICATIONS
7.3
DISPLAY UNIT
7-13
7
INSTRUCTION MANUAL
7.3.2 OPERATION PANEL
(1) Structure Integrated on the display unit
(2) Controls GAIN
SEA
RAIN
MULTI
Cursor keys
(3
)Keys
STBY Stops transmission (Turns off the equipment if
simultaneously pressed with "TX/PRF")
TX/PRF Starts transmission (Turns off the equipment if
simultaneously pressed with "STBY")
Changes PRF during transmission. Clears SHM when
held down.
RANGE+ Increases the distance range.
RANGE- Decreases the distance range.
FUNC Switches the function.
BRILL Adjusts LCD brightness
ENT Enter key (Selects menu items, etc)
CLEAR Cancels operations
MENU Opens/closes the menu screen
Soft key 1 Soft key 1
Soft key 2 Soft key 2
Soft key 3 Soft key 3
Soft key 4 Soft key 4
7.3.3 AIS FUNCTION
(1) Screen
Number of targets Up to 50 targets (stores up to 500 ship static data)
Target information Displays MMSI, call sign, ship name, COG, SOG,
CPA, TCPA, direction, distance, latitude, longitude,
status, etc.
Filters Distance only
Active targets Not available
Dangerous ship targets No CPA/TCPA decision
(2
) Operation Built-in
