Chapter 2
OPERATIONS
2.10
RADAR TRAIL LENGTH SETTING
2-85
2
INSTRUCTION MANUA
z Maximum value of radar trail display time
Select Short when short radar trails are often used in bays and the likes.
Select Super Long when long radar trails are necessary for ocean navigation.
Middle is for specification between Short and Long .
Continuous trails are available with all the options.
Short:
Off/15sec/30sec/1min/2min/3min/4min/5min/6min/10min/15min/All
Middle:
Off/30sec/1min/2min/3min/4min/5min/6min/10min/15min/30min/All
Long:
Off/1min/2min/3min/4min/5min/6min/10min/15min/30min/1hr/All
Super Long:
Off/30min/1hr/2hr/3hr/4hr/5hr/6hr/10hr/12hr/24hr/All
