Chapter 4

MAINTENANCE
4.5

FAULT FINDING
4-21
4
INSTRUCTION MANUAL
Alarm name
(Japanese)
Alarm name
(English)
Class Description
ࣟࢢ ↓㏻ಙ Log(Time Out) Alarm For speed equipment=log, cannot receive valid sentences
(including checksum error) which had been received properly.
ࢪࣕ࢖ࣟ ㏻ಙࢹ࣮ࢱ GYRO(Data) Alarm For heading equipment=Gyro, the GYRO error bit of NSK
communication data is set.
ࣟࢢ ㏻ಙࢹ࣮ࢱ Log(Data) Alarm For speed equipment=log, the LOG error bit of NSK
communication data is set.
㔪㊰ ↓㏻ಙ Heading(Time Out) Alarm For heading equipment=compass, cannot receive valid NMEA
bearing sentences (including checksum error) which had been
received properly.
㔪㊰ ㏻ಙࢹ࣮ࢱ Heading(Data) Alarm For heading equipment=compass, cannot receive valid NMEA
bearing data which had been received properly.
2㍈ᑐᆅ ↓㏻ಙ 2AXG(Time Out) Alarm For speed equipment=2-axis log, cannot receive valid VBW
sentences (including checksum error) which had been received
properly.
2㍈ᑐᆅ ㏻ಙࢹ࣮ࢱ 2AXG(Data) Alarm For speed equipment=2-axis log, cannot receive valid VBW
ground data which had been received properly.
GPS ࢚࣮ࣛ GPS(Error) Status Failed to set GPS.
GPS ↓㏻ಙ GPS(Time Out) Alarm Cannot receive valid GPS sentences (including checksum error)
which had been received properly.
GPS ఩⨨ࢹ࣮ࢱ GPS(Position) Alarm Cannot receive valid position data which had been received
properly
GPS ᆅ⣔ࢹ࣮ࢱ GPS(Datum) Alarm Cannot receive valid geodetic data which had been received
properly
GPS ㏿ᗘࢹ࣮ࢱ GPS(Speed) Alarm For speed equipment=GPS, cannot receive valid speed data which
had been received properly
GPS ఩≧ែ GPS(Status) Alarm Received GPS fixing status error (invalid)data
Ỉ῝ ↓㏻ಙ Depth(Time Out) Alarm Cannot receive valid depth sentences (including checksum error)
which had been received properly
Ỉ῝ ㏻ಙࢹ࣮ࢱ Depth(Data) Alarm Cannot receive valid depth data which had been received properly
Ỉ ↓㏻ಙ TEMP(Time Out) Alarm Cannot receive valid water temperature sentences which had been
received properly
Ỉ ㏻ಙࢹ࣮ࢱ TEMP(Data) Alarm Cannot receive valid water temperature data which had been
received properly
㢼ྥ㢼㏿ ↓㏻ಙ Wind(Time Out) Alarm Cannot receive valid wind direction/windvelocity sentences
(including checksum error) which had been received properly
㢼ྥ㢼㏿㸦┿㸧 ㏻ಙ㺡㺼㺎㺞 Wind True(Data) Alarm Cannot receive valid water temperature data after valid wind
direction/wind velocity (true) data had been received properly
