JRC JMA-3300 Series User Manual

Chapter 4

MAINTENANCE
4.6

TROUBLE SHOOTING
4-32
7ZXRD0028 : Display unit NDC-2182
Name/Type Parts No. Code Shape (mm) Spare Location Application
Connector

LTWBD-06BFFA-
LL7001
P3 5JCDX00032
1
Inside
processing
unit
Mainly for GPS
connection
Connector

LTWBD-08BFFA-
LL7001
P5 5JCDX00034
1
Inside
processing
unit
Mainly for connecting
course equipment such
as a GPS compass
Connector

LTWBD-07BFFA-
LL7001
P6 5JCD00033 1
Inside
processing
unit
For AIS connection
For connecting other
external devices when
the AIS is not used
For acquiring 2-axis
logs, current data, and
wind direction data
44.0
18.0
44.0
18.0
44.0
18.0
