Chapter 7
SPECIFICATIONS
7.1
GENERAL SPECIFICATIONS
7-2
(13) Power Consumption In calm wind:
Approx. 60W(NKE-2042)
Approx. 60W(NKE-2043)
Approx.85W(NKE-2062)
Approx.85W(NKE-2063$)
Approx. 85W(NKE-2062HS)
Approx. 85W(NKE-2063+6$+6
Approx. 100W(NKE-2103-4)
Approx. 100W(NKE-2103-4HS)
Approx. 100W(NKE-2103-6)
Approx. 100W(NKE-2103-6HS)
Maximum (Velocity of the wind: 100 kn):
Approx. 60W(NKE-2042)
Approx. 60W
(NKE-2043)
Approx.230W(NKE-2062)
Approx.180W (NKE-2063$)
Approx. 230W(NKE-2062HS)
Approx. 230W(NKE-2063HS$+6)
Approx. 360W(NKE-2103-4)
Approx. 360W(NKE-2103-4HS)
Approx. 360W(NKE-2103-6)
Approx. 360W(NKE-2103-6HS)
(14) Range of power supply voltage fluctuation
+10.8 to 41.6 VDC (Display Unit) (4kW/6kW)
+21.6 to 31.2 VDC (Display Unit)
(6kWHS/10kW/10kWHS)
(15) Pre-heating Time Approx. Within 1min30sec
(16) Scanner Refer to Scanner Specifications
(17) Display unit Refer to Display Unit Specifications
(18) Inter-Unit Cables Using common scanner connecting cable CFQ-6912-**
Maximum cable length: 30 m
