JRC JMA-3300 Series User Manual

APPENDIX
APPENDIX-
……………….……………..
8) Description of accessories and components, including software:
System Components
JMA-3334 JMA-3336 JMA-3336HS JMA-3340-4 JMA-3340-4HS JMA-3340-6 JMA-3340-6HS
Display Unit NCD-2182 X X X X X X X
4kW Radome Scanner Unit NKE-2043 X
6kW Slot Antenna Scanner Unit
NKE-2063A
X
6kW Slot Antenna Scanner Unit/
Hi
g
h s
p
eed craft
NKE-2063A+6
X
10kW Slot Antenna Scanner Unit NKE-2103-4 X
10kW Slot Antenna Scanner Unit/
High speed craft
NKE-2103-4HS
X
10kW Slot Antenna Scanner Unit NKE-2103-6 X
10kW Slot Antenna Scanner Unit/
High speed craft
NKE-2103-6HS
X
Software version:
Scanner Unit NKE-2043 V03.00
Scanner Unit NKE-2063A2063A+6 V03.00
Scanner Unit NKE-2103-4/4HS/6/6HS V02.11
Display Unit NCD-2182 V01.00 or V01.01
9) Additional Information:
Antenna length 2ft, Peak power 4kW(Magnetron) X-Band Scanner Unit:NKE-2043
Antenna length 3.9ft, Peak power 6kW(Magnetron) X-Band Scanner Unit:NKE-2063A
Antenna length 3.9ft, Peak power 6kW(Magnetron) X-Band Scanner Unit:NKE-2063A+6
Antenna length 4ft, Peak power 10kW(Magnetron) X-Band Scanner Unit:NKE-2103-4
Antenna length 4ft, Peak power 10kW(Magnetron) X-Band Scanner Unit:NKE-2103-4HS
Antenna length 6ft, Peak power 10kW(Magnetron) X-Band Scanner Unit:NKE-2103-6
Antenna length 6ft, Peak power 10kW(Magnetron) X-Band Scanner Unit:NKE-2103-6HS
10inch LCD Display Unit:NCD-2182
Signed for and on behalf of: Japan Radio Co., Ltd., Tokyo, Japan.
Place and date of issue:
Nagano-shi, Nagano ,Japan Dated 8
th
June 2017
Navigation Group
Quality Assurance Department
Marine Systems
Name/function: Hiroshi Isohata / Manager
Signed:
Code: 7ZPRD0971

JRC JMA-3300 Series Specifications

General

Brand	JRC
Model	JMA-3300 Series
Category	Radar
Language	English
