Chapter 1
GENERAL AND EQUIPMENT COMPOSITION
1.4
EXTERIOR DRAWINGS
1-11
INSTRUCTION MANUA
L
1
Fig. 1.4-5 Exterior Drawing of Scanner Unit, Type NKE-2103-4/4HS
