Chapter 2
OPERATIONS
2.7
SOFT KEY OPERATION
2-50
Creating a fan-shaped radar alarm/acquisition area
1 Perform the following settings.
Soft key 2: When Alarm1 is selected
Sector AZ1
When Alarm2 is selected
Sector AZ2
The range setting is started for a fan-shaped radar alarm/acquisition area.
2 Press the cursor keys to move the cursor to the first point (setting of the start
bearing and range), then press the [ENT] key.
3 Press the cursor keys to move the cursor to the second point (setting of the
end range), then press the [ENT] key.
To Next Page
