Chapter 5 VARIOUS FUNCTIONS
11
5.29.3 MARK TYPE
Select the type of mark.
The type of mark can be selected from , 㸩, Y or .
5.29.4 DISPLAY MARK COLOR
Display the marks with the specified color.
When “All” is set to All, the setting of “All” is prior to individual settings.
When “All” is set to Individual, individual settings are prior to the setting of “All.”
5.29.5 DISPLAY MARK TYPE
Display the marks with the specified type.
When “All” is set to All, the setting of “All” is prior to individual settings.
When “All” is set to Individual, individual settings are prior to the setting of “All.”
5.29.6 MARK LIST
Display the list of marks which are on the radar screen.
ڦThe mark can be created or modified by operating on the list.
Procedure for creating new mark
1. Press the GAIN control.
2. The dialog as below is displayed.
3. Input the No.2 to No.5 items.
4. Select No.6 “Enter”, the mark can be created.
To Next Page
