Chapter 13 SPECIFICATIONS
2
4
13.7.2 OUTPUT POSSIBLE SIGNAL
࣠NMEA0183 output sentences
(1) Navigation equipment
Radar date: RSD
Own ship’s data: OSD
TT data: TTM, TLL, TTD
Latitude/ Longitude data: GGA, RMC, GNS, GLL,
COG/SOG: RMC, VTG (Received GPS data)
Bearing signal: THS, HDT (Received GPS Compass data)
(2) External Buzzer Open collector contacts one port. (NMEA cable option necessary)
(3) Output RGB signal
࣠CAN output PGN
PGN Contents
Explanation
128259 Speed, water referenced
A single transmission
128267 Water depth
Including relative to the transducer and offset.
129283 XTE
Position error perpendicular to the desired course.
129284 Navigation Data
An essential navigation data for following a route.
129285 Navigation-Route/WP information
Route and WP data ahead in the Active Route.
129026 COG, SOG rapid update
Provides COG and SOG.
129029 GNSS position
GNSS parameters, including position information.
130310 Water temp
Water temperature
13.7.3 STANDARD CONFIGURATION
Scanner: 1unit
Display Unit: 1unit
Power cable: 1pc. (3m)
Instruction manual: 1 book (Including Installation manual and Quick manual)
13.7.4 OPTION CABLE
Installation cable:
Cable length Cable type
5m H-CFQ-6912-5
10m H-CFQ6912-10
15m CFQ-6912-15
20m H-CFQ6912-20
30m H-CFQ6912-30
NMEA cable (waterproof (IPX5)):
Description Cable type
CFQ-9002 GPS cable
CFQ-5374 NMEA0183 cable
CFQ-7765 CAN cable (Connector kinds: Socket side – Socket side)
