Chapter 7 INITIAL SETTINGS

7.8.3 BEACON SETTING

Set for a JRC Beacon (DGPS receiver). This setting is available only for JRC Beacon receiver (DGPS

receiver).

AUTO: Select an optimum beacon station automatically.

Manual: The beacon frequency and baud rate need to be set manually.

Note: This setting is enabled when “Station Select” is set to ”Manual.”

Select

Automatic/manual selection of stations.

Frequency

Set “beacon frequency.”

Baud Rate

Selection of beacon bit rate.

Send Data㻌

Select each setting item.
