Chapter 8 DETAIL PERFORMANCE
1
63
8.5.3 MULTI CONTROL
Set the cursor movement amount when MULTI control is operated.
The larger the value is, the greater the amount of movement is, or vice versa.
 EBL: Set the amount of movement when turning the dial to set EBL.
 VRM: Set the amount of movement when turning the dial to set VRM.
Common: Set the amount of movement when turning the dial for Parallel cursor.
8.5.4 GAIN CONTROL/SEA CONTROL/RAIN CONTROL
Set the settings of GAIN/SEA/RAIN control.
Select "Response Level", and set the response level. If you set a large value, the amount of movement will
also increase.
Select "Min Preset", and set the gain when turning the control to minimum position.
Select "Max Preset", and set the gain when turning the control to maximum position.
