Chapter 5 VARIOUS FUNCTIONS
1
5.23.3 TRAILS INTERVAL
Set the interval of radar trails.
The options in this menu depend on the setting of MAX Interval (refer to “5.23 FUNCTION SETTING”, “8.2
TRAILS”).
If MAX Interval setting is changed, this menu is set the shortest interval in the setting (except “Off”).
5.23.4 ANTENNA HEIGHT
Set the antenna height used in the function mode.
When default is selected, the value set in the Basic Adjustment is applied.
For Basic Adjustment, refer to “7.5 ANTENNA HEIGHT SETUP.”
5.23.5 SAVE PRESENT STATE
Not function setting but the current status set in the main menu (for example, “5.16 RADAR ECHO SETTING”
and “5.20 TRAILS SETTING”) is saved as the setting value of the selected function mode.
The confirmation dialog window is displayed. Select “YES”, the operation is executed.
5.23.6 Reset To User Default
The setting value reset to setting when user executed Table Update (3.Initial Value/2.Function Setting) .
About the Table Update, refer to “8.7.5 TABLE UPDATE.”
Hint: After the radar echo adjustment when installed the radar, recommend executing Table Update. Because
your initial setting value is when your radar was installed.
([HFXWHWKLVIXQFWLRQ$UH\RXVXUH"
([HFXWHWKLVIXQFWLRQ$UH\RXVXUH"
5HVHW7R8VHU'HIDXOW
