Chapter 5 VARIOUS FUNCTIONS

5.23.7 INITIALIZE

Initialize a selected function setting mode. The initialized mode values are set to the factory-set values.

About the factory-set values of each function setting mode, refer to “5.13 SWITCH THE FUNCTION.”

The confirmation dialog window is displayed. Select “YES”, the operation is executed.

([HFXWHWKLVIXQFWLRQ$UH\RXVXUH"


