JRC JMA-3406 User Manual

212
Chapter 10 MAINTENANCE AND CHECK
10.6.2 CIRCUIT BLOCK TO BE REPAIRED
JMA-3404
Location Circuit Block Type Remarks
Scanner Motor unit 7BDRD0052*
Scanner
Compound Modulator
Circuit
CME-385
Scanner Receiver NRG-239 Include CAE-548
Display Unit Processing circuit CDC-1497
Display Unit TT circuit CDC-1498
Display Unit Keyboard circuit CCK-1141
Display Unit USB/SD I/F circuit CMH-2515
Display Unit Power supply circuit CBD-2028
Display Unit I/F circuit CMH-2512
Display Unit Scanner I/F circuit CMH-2513
Display Unit Power supply I/F circuit CMH-2514
Display Unit LCD module CML-872
Display Unit Fuse MF60NR 250V 10 F1
"*" means revision, such as A, B and so on.
JMA3406/HS
Location Circuit Block Type Remarks
Scanner Motor unit CBP-218
Scanner
Compound Modulator
Circuit
CME-386A
Scanner Receiver NRG-239 Include CAE-548
Display Unit
Processing circuit CDC-1497
Display Unit
TT circuit CDC-1498
Display Unit
Keyboard circuit CCK-1141
Display Unit
USB/SD I/F circuit CMH-2515
Display Unit
Power supply circuit CBD-2028
Display Unit
I/F circuit CMH-2512
Display Unit
Scanner I/F circuit CMH-2513
Display Unit
Power supply I/F circuit
CMH-2514
Display Unit
LCD module CML-872
Display Unit
Fuse MF60NR 250V 10 F1
