Chapter 13 SPECIFICATIONS
13.6 DISPLAY
13.6.1 INTEGRATED DISPLAY UNIT (NCD-2364)
1) Structure Desk Top Integrated Type
(LCD Monitor Unit/Keyboard Unit/Processor Unit Integrated Structure)
Vertical installation only desk top integrated type
2) Dimensions Without bracket and side knob
Height 320mm × Width 320mm × Depth 95.1mm
Including bracket and side knob
Height 340mm × Width 342mm × Depth 95.1mm
(Depth is the depth from the front panel, not including the
control knobs.)
3) Mass Approx. 5 kg
4) Tune Method Manual / Auto
(Bar-graph indication is displayed at the time of adjustment.)
5) STC (SEA) Manual / Auto
6) FTC (RAIN) Manual / Auto
7) Radar Interference Rejection Built-in (The effect can be adjusted by three stages.)
8) Bearing Marker 360° in 5° digit
9) Heading Line Electronic (Can be temporarily hidden)
10) Off Center Move to the defined coordinates of 4 patterns
11) True Motion Unit Built-in (Not available at the maximum range)
12) True Motion Reset Position 66% of radius of any range
13) Radar trail indication True motion mode: Only true motion trails
Relative motion mode: True or relative motion trails
Trail time length:
Short: 15sec/30sec/1min/2min/3min/4min/5min/6min
/10min/15min/Continuous
Middle: 30sec/1min/2min/3min/4min/5min/6min/10min
/15min/30min/Continuous
Long: 1min/2min/3min/4min/5min/6min/10min/15min/
30min/1hr/Continuous
Super Long: 30min/1hr/2hr/3hr/4hr/5hr/6hr/10hr/12hr
/24hr/Continuous
The trail length can be switched instantaneously.
Possible to display time series trail and continuous trail by
color classification.
Even if the movement mode, bearing mode, or range is
changed, the radar trails can be taken over.
