Chapter 1 INSTALLATION
1
1.2.6 EXTERNAL NAVIGATIONAL SIGNAL CONNECTION
(GPS, AIS, GYRO, LOG, etc.) Connecting cable is option
Option NMEA cable: “CFQ-9002 (GPS)”, “CFQ-5374 (NMEA0183)”
In case of using option NMEA cable, waterproofing (IPX5) is guaranteed. Thus, using another NMEA cable,
waterproofing (IPX5) is not guaranteed.
࣭Using JRC GPS receiver, please connect NMEA4 (GPS port).
࣭AIS connects all NMEA port available.
Navigation system interfaces, such as GPS
Telecommunications standard NMEA0183 / IEC61162-1/2 conformity
Communications protocol: 4800 bps, start 1bit, data 8bit, stop 1bit, and no parity
Input sentence NMEA0183: V1.5: GGA/ GLL/ RMC
V2.0: GGA/ GLL/ RMC/ ZDA
V2.3: GGA/ GLL/ RMC/ GNS/ ZDA
(Talker= "G P" etc.)
Information ship position and the time; GGA/ GNS/ GLL/ RMC
Day ZDA
Time of equipment: ZDA/ GGA/ GNS/ GLL/ RMC
Reference :
NMEA0183 content outline of standard input / output sentence
$xxACK Acknowledgement alarm
$xxBWC Bearing and Distance to Waypoint
$xxCUR Water current layer
$xxGGA Global Positioning System Fix Data
$xxGLL Geographic Position - Latitude/Longitude
$xxGNS GNSS fix data
$xxMTW Water temperature
$xxMWD Wind direction and speed
$xxMWV Wind speed and angle
$xxRMA Recommended Minimum Specific LORAN-C data
$xxRMB Recommended Minimum Navigation Information
$xxRMC Recommended Minimum Specific GNSS Data
$xxROT Rate Of Turn
$xxRSA Rudder Sensor Angle
$xxTHS True Heading and Status
$xxVBW Dual ground/water speed
$xxVDM AIS VHF Data-link Message
$xxVDO AIS VHF Data-link Own-vessel report
$xxVTG Course Over Ground and Ground Speed
$xxZDA Time and Date
To Next Page
