Chapter 13 SPECIFICATIONS
30) Interface
DVI port DVI-D 1 port. SVGA (800600 pixel)
GPS port 1 port
Can be used as a JRC GPS port or NMEA0183 (NMEA4 TX/RX)
port. Compatible with IEC61162-1/2 equivalent when used as
NMEA0183 port.
NMEA0183 port 3 ports (NMEA1 to NMEA3 TX/RX)
Compatible with IEC61162-1/2 equivalent
LAN port 1 port. Communication between JMA-3400 and display unit.
Dry contact output Output the external alarms. Normally Open only.
Contact input Input the event marks.
CHART CARD port Support for new pec and Navionics+ charts.
USB port 2 ports (front/rear).
Front port: Save internal data.
Rear port: For mouse / trackball connection only.
31) Waterproof/dustproof IP55. However, the following usage conditions are
assumed.
The front “CHART CARD/USB” cover is closed.
Close the “USB, LAN, DVI” cover on the back.
The optional rubber cap (MTT317838) is attached to the
cable connected to the “SCANNER” connector on the
back.
32) EMC IEC60945 Ed.4.0
However, this is not applicable if any of the following ports
are used.
࣭"CHART CARD/USB" port on the front.
࣭"USB, DVI" port on the back.
13.6.2 OPERATIONAL PART
1) Structure Integrated on the display unit
2) POWER ON/OFF ON: [STBY]
OFF: Press [STBY] and [TX / PRF] simultaneously
3) Pointing device Cross key
4) Keys ENT, CLR, MENU, FUNC, USER1, USER2, EBL, VRM,
TX/PRF, STBY
5) Controls GAIN, SEA, RAIN, BRILL, MULTI
