JRC JMA-3406 User Manual

Chapter 13 SPECIFICATIONS
2
30
14) Variety of Pulse width JMA-3404, JMA-3406/HS
SP1/SP2/SP3/MP1/MP2/LP1/LP2
JMA-3411-4/4HS/6/6HS
SP/MP1/MP2/LP1/LP2
15) Target enhance 4 stages
16) Plotting
Line/Own Track 7 colors (White, Cyan, Blue, Green, Yellow, Pink, Red)
3 types (solid line, dashed line (short), dashed line (long))
Mark 4 types (X, +, Y, )
2 sizes (Small, Large)
7 colors (White, Cyan, Blue, Green, Yellow, Pink, Red)
The maximum number of points: 10,000.
17) Display color
Radar echo 8 colors (Yellow, Green, Orange, Pink, Red, White, Color, Custom)
Radar trails Time trails: 3 colors (Cyan, White, Green)
Continuous trails: 3 colors (Dark Green, Gray, Navy Blue)
Background (inner PPI) 4 colors (Blue, Navy Blue, Black, White)
Background (outer PPI) 4 colors (Blue, Navy Blue, Black, White)
Characters 7 colors (White, Cyan, Orange, Green, Black, Red, Amber)
AIS/TT 3 colors (Cyan, Green, White)
EBL/VRM 6 colors (Cyan, Green, Orange, Black, Pink, White)
Cursor 4 colors (Red, Yellow, Pink, White)
Own Ship/Barge 4 colors (White, Cyan, Green, Red)
Range Ring 6 colors (Cyan, Orange, Red, Green, White, Amber)
Guard Zone 5 colors (White, Green, Orange, Black, Red)
18) Simulator Built-in
19) Multiple languages English, Japanese, Other one optional language
20) Range Unit NM, km, sm
21) Data-OFF screen Only minimal information. Display radar image in full screen.
22) TLL Transmit TLL (NMEA sentence) can be transmitted to the external device by
pressing the operation button.
23) Screen Capture Screen can be captured by pressing button or automatically
(saved in USB memory).
24) Barge Outline Display 1 ship (own ship + barge).
25) GPS receiver JRC GPS receivers (JLR-4340, JLR-4341) can be connected,
GPS settings and reception status can be checked.
26) Navigation information Standard Built-in
The standby screen can be changed to a graphical
screen.
27) AIS information display Refer to AIS function.
28) TT function Built-in Refer to TT function.
29) Waypoint display One mark of position information
