Alarm Name
*Screen notation
Class Description
Area1(Approach) Alarm
Echo in area1.
Area1(Secession) Alarm
No echo in area1.
Area1(Out of Range) Alarm
Rectangle area 1 is out of range.
Creation of area 1 is out of range.
Area2(Approach) Alarm
Echo in area2.
Area2(Secession) Alarm
No echo in area2.
Area2(Out of Range) Alarm
Rectangle area 2 is out of range.
Creation of area 2 is out of range.
TT(CPA/TCPA) Alarm
TT is changed to a dangerous ship
TT(New Target) Alarm
TT is automatically acquired.
TT(Lost) Alarm
TT is lost.
Dragging anchor Alarm
The ship has left the dragging anchor monitoring area.
GPS(Error) Status
Failed to set GPS.
GPS(HDOP) Caution
Received excessive HDOP value beyond the setting.
TM Reset Status
For TM, the own ship position is out of 40% of the radius of
PPI.
No Heading Data Status
Cannot function because own ship heading is not available
- Operations for specifying TT
acquisition/numerical display
- Changing to TM
- Changing to N Up/C Up
On Preheating Status
Transmission operation during preheating
Short Interval Status
Transmission operation in the interval of 1 second or less
between standby and transmission
Error Occurring Status
Transmission operation during prohibition of
transmission caused by scanner error
Max Point Status
Exceeded the maximum number of marks.
File Not Found Status
File does not exist.
USB Memory Not Set Status
USB memory does not exist.
SD Memory Not Set Status
SD memory does not exist.
File Read Error Caution
Failed to load the file.
File Write Error Caution
Failed to write the file.
Not Enough Space Status
Insufficient capacity.
Format Error Caution
Failed to format.
Num of files Over Caution
Writing data to the USB memory in which the number of the
file has reached to the maximum.
File Erase Error Caution Failed to delete the file.
TT(Max Target) Status
Manually acquired when the number of acquisitions
reached maximum.
Detected when DSP tries to acquire 11 targets or more.
DSP notifies the maximum target alarm occurrence of
automatic acquisition tot the TT process task, then the TT
process task notifies it to the alarm task.
Unsetting Status
Zone creation operations for guard zone = Off.
EBL bearing setting while EBL is off.
Floating setting while EBL/VRM is off.
VRM range setting while VRM is off.
Manual tuning setting while automatic tuning is on.
AIS operations while AIS function is off.
TT operations while TT function is off.
Invalid Data Status
Cannot function due to invalid value
- Invalid code is input for the code input screen
