JUKI PS-700 - Attaching the Needle; Threading the Machine Head

– 13 –
2) Loosen setscrew
❶
at needle bar thread holder
❷
section. Insert needle
❸
into the needle bar until it will
go no further. At this time, scarf section
B
of needle
❸
must face the opposite side of the operator. In this
state, tighten setscrew
❶
.
4-2. Attaching the needle
❶
❷
❸
B
Opposite side
of operator
1) Press the key on the main screen P1 to lower the intermediate presser. In this state, attach the nee-
dle. (The needle to be used : Organ needle DB × 1, #9 to 16)
4-3. Threading the machine head
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
