1. SPECIFICATIONS
I. MECHANICAL SECTION
1 Sewing area X (lateral) direction : 1,200 mm × Y (longitudinal) direction : 700 mm
2 Max. sewing speed 3,000 sti/min (When stitching pitch is 3 mm or less)
3 Settable stitch length 0.1 to 12.7 mm
4 Feed motion of feeding frame Intermittent feed (2-shaft drive by stepping motor)
5 Needle bar stroke 39.8 mm
6 Needle Organ needle DB × 1 #9 to 16
7 Thread Filament #50, Span #30
8 Lift of disc presser Max. 13 mm
9 Intermediate presser stroke 4 mm (Standard) (4 to 8.7 mm)
10 Lift of intermediate presser 23 mm
11 Hook Double-capacity full-rotary hook
12 Lubricating oil JUKI CORPORATION GENUINE OIL 7 (Supplied by oiler)
13 Memory of pattern data Main body : Max. 999 patterns (Max. 60,000 stitches/pattern)
External media : Max. 999 patterns (Max. 60,000 stitches/pattern)
14 Temporary stop facility Used to stop machine operation during a stitching cycle.
15 Enlarging / Reducing facility Allows a pattern to be enlarged or reduced on the X axis and Y axis inde-
pendently when sewing a pattern.
Scale : 10 to 400 % (0.1 % steps)
16 Enlarging / Reducing method Pattern enlargement / reduction can be done by increasing / decreasing
either stitch length or the number of stitches. (Increasing/decreasing
stitch length only can be performed when pattern key is selected.)
17 Max. sewing speed limitation 200 to 3,000 sti/min (100 sti/min steps)
18 Pattern selection facility Pattern No. selection method
(Main body : 1 to 999, External media : 1 to 999)
19 Bobbin thread counter UP/DOWN method (0 to 99,999)
20 Sewing counter UP/DOWN method (0 to 99,999)
21 Memory back-up In case of a power interruption, the pattern being used will automatically
be stored in memory.
22 2nd origin setting facility Using jog keys, a 2nd origin (needle position after a sewing cycle) can be
set in the desired position within the sewing area. The set 2nd origin is
also stored in memory.
23 Sewing machine motor Servo-motor
24 Dimensions 1,870 mm (W) × 2,130 mm (L) × 1,410 mm (H) (Excluding thread stand)
25 Mass (gross mass) 722 kg
26 Power consumption 255.3 VA
27 Operating temperature range 5 to 35 ˚C
28 Operating humidity range 35 to 85 % (No dew condensation)
29 Storage temperature range -20 to 60 ˚C
30 Storage humidity range 10 to 85 % (No dew condensation, 85 % applies to the case where the
temperature is 40 ˚C or lower)
31 Line voltage Single phase 220 to 240 V
32 Air pressure used 0.5 to 0.55 MPa (Max. 0.7 MPa)
33 Needle highest position stop
facility
After the completion of sewing, the needle can be brought up to its high-
est position.
34 Noise
- Equivalent continuous emission sound pressure level (L
pA
) at the work-
station :
A-weighted value of 76.0 dB ; (Includes K
pA
= 2.5 dB) ; according to
ISO 10821- C.6.2 -ISO 11204 GR2 at 2,500 sti/min.
