JUKI PS-700 - Configuration

– 2 –
Air control device
2. CONFIGURATION
❶
Machine head
❷
Table
❸
X-axis feed mechanism
❹
Y-axis feed mechanism
❺
Cassette clamp device
❻
Operation panel
❼
Air control box
❽
Electrical control box
❾
Power switch (also used as the emergency
stop switch)
󱢳
Thread stand
󱢴
Bobbin winder device
❶
❷
󱢴
❸
❹
❻
❼
❾
❺
❽
󱢳
