– 5 –
8) Temporarily x bobbin winder tension controller
(asm.)
on bobbin winder device mounting plate
❶
with nut
.
9) Aligning shorter thread guide section
C
of bobbin
winder tension controller (asm.)
with the direc-
tion of bobbin
, tighten nut
.
10) Pass the thread through thread guide
, bob-
bin winder tension controller (asm.)
in the
written order. Then, wind thread on bobbin
.
Take care not to allow the top end
of screw of bobbin winder tension
controller (asm.)
to protrude from the
end face of nut
in order to prevent
hands and ngers from being injured.
If bobbin
is wound with thread
unevenly, loosen nut
and adjust the
direction of rotation of thread guide
section
C
.
9)
10)
8)
❶
C
Top end of the screw must not
protrude from this section.
C
