Wordclock output 2.4V (typ.) @ 75Ohm single-ended
Network Interface RJ45 connector, 10/100Mbit Ethernet auto sense, full duplex, auto MDI/X
USB Interface USB 2.0 connector to internal console interface
8 general purpose inputs (GPI), divided into 2 groups with separate
common signal, isolated
Connector type D-Sub25 connector female, same for GPO
Input conditions 3 … 24Vdc, < 5mA
GPI Signals
Auxiliary supply 5V (nom.), 200mA (max.), isolated
8 general purpose outputs (GPO), SPST, divided into 2 groups with
separate common signal, isolated
Connector type D-Sub25 connector female, same for GPI
GPO Signals
Output conditions 24Vac/dc (max.), 120mA (max.)
Expansion Slot 1 general purpose expansion slot for option boards
Power Supply Dual power supply, automatic fail over,
85 … 264Vac, 50 … 60Hz, 58W (max.)
Environmental Operating temperature 0 … 50ºC, fan cooled,
Non-operating -20 … 70ºC,
Humidity < 90%, non-condensing
Physical 19", 1 RU, 27 cm depth, net weight ca. 5 kg, shipping weight ca. 7.5 kg
Technical Data – Option Board SDI I/O (3G/HD/SD) [O_DAP_SDI_a]
Standards Video complies with SMPTE 424/425M (3G, Level A and B), SMPTE 292M
(HD) or SMPTE 259M (SD). Automatic format detection.
Audio embedding and de-embedding complies with SMPTE 299M (3G,
HD) or SMPTE 272M-AC (SD).
Metadata embedding and de-embedding complies with SMPTE 2020-2.
Video Data Rate 2970/2967Mbps (3G), 1485/1483.5Mbps (HD), 270Mbps (SD)
Video Formats 1080p23.975, 24, 25, 29.97, 30, 50, 59.94, 60
1080i50, 59.94, 60
720p23.975, 24, 25, 29.97, 30, 50, 59.94, 60
625i50, 525i59.94, …
Video Delay User selectable 0 …15frames, can be disabled
Audio 24bits, transparent forwarding of PCM and compressed audio
Audio Channels 16 inputs and 16 outputs (4 groups with 4 channels each)
Audio Sample Rate 48kHz (SDI compliant)
Audio Delay Embedder audio delay selectable 0 … 320 ms per channel
Metadata (RDD6) 1 channel input and 1 channel output, SDID selectable
Impedance 75Ohm
Return loss > 15dB, 5 … 1485MHz
> 10dB, 1485 … 2970MHz
BNC Input
Cable length (max.) 250m @ SD for Belden 1694A cable
230m @ HD for Belden 1694A cable
140m @ 3G for Belden 1694A cable
