junger D*AP4 FLX - Technical Data - Option Board MADI I;O, Optical [O_Dap_Mo_Mm_A]; Technical Data - Option Board MADI I;O, Optical [O_Dap_Mo_Sm_A]

D*AP4
77
Output voltage 0.6Vpp (typ.) @ 75Ohm
General Features
• Input cable equalizer for extended range and robustness
• Reference grade word clock recovery, master-sync capable
• Dedicated routing for non-processed channels, all channels
(max. 64) can be routed to/from the device or looped through
• AES3 channel status management, non-audio detection
Technical Data – Option Board MADI I/O, Optical [O_DAP_MO_MM_a, O_DAP_MO_SM_a]
Standards Relevant specifications comply with AES10-2008 and AES11-2009.
Audio 24bits, transparent forwarding of PCM and compressed audio
Audio Sample Rate 44.1, 48, 88.2, 9kHz, (88.2, 96kHz short framing)
64/56 channels @ 44.1 and 48kHz, 32/28 @ 88.2 and 96kHz
Processable by D*AP8: 16 channels @ 44.1, 48kHz
Processable by D*AP4: 8 channels @ 44.1, 48, 88.2, 96kHz
Connector type LC (IEC 61754-20)
Center wavelength 1310nm (typ.), 1270 … 1360nm
Optical Input, LC
Input optical power [O_DAP_MO_MM_a]:
-31 … -8dBm, OM2 multimode (50/125µm)
[O_DAP_MO_SM_a]:
-23 … -8dBm, singlemode (9/125µm)
(standard values, others on request)
Cable length (max.) [O_DAP_MO_MM_a]: 1.5km, OM2 multimode
[O_DAP_MO_SM_a]: 2km, singlemode
(standard values, others on request)
64/56 channels @ 44.1 and 48kHz, 32/28 @ 88.2 and 96kHz
Processable by D*AP8: 16 channels @ 44.1, 48kHz
Processable by D*AP4: 8 channels @ 44.1, 48, 88.2, 96kHz
Connector type LC (IEC 61754-20)
Center wavelength 1310nm (typ.), 1270 … 1360nm
Optical Output, LC
Output optical power [O_DAP_MO_MM_a]:
-23 … -14dBm, OM2 multimode (50/125µm)
[O_DAP_MO_SM_a]:
-15 … -8dBm, singlemode (9/125µm)
(standard values, others on request)
Optical and BNC output carry the same signal.
Impedance 75Ohm
BNC Output
Output voltage 0.6Vpp (typ.) @ 75Ohm
General Features
• Field-replaceable optical module (SFP)
• Reference grade word clock recovery, master-sync capable
• Dedicated routing for non-processed channels, all channels
(max. 64) can be routed to/from the device or looped through
• AES3 channel status management, non-audio detection
• Parallel outputs (BNC/LC) for media conversion
