Operating – menu structure of the X*AP RM 1 remote panel – menu tree
Power Up Display – select a remote device
<MENU> opens X*AP RM 1 remote panel IP setup menu.
Hotkey #
1 <Address> setup
2 <Netmask> setup
3 <Gateway> setup
4 < empty >
5 Device 1 setup IP & ON / OFF
6 Device 2 setup IP & ON / OFF
7 Device 3 setup IP & ON / OFF
8 Device 4 setup IP & ON / OFF
<ESC> back to power up display
<connect> will connect with that particular D*AP4 and opens the main operating display:
Hotkey #
1 <R128>
2 <ITU1770>
3 <Loudn Lim>
4 <D02>
5 <Limiter!>
6 <Nicerizer>
7 <[Panic 1>
8 <Panic 2]>
<ESC> will jump back to power up display
<MENU> opens upper operating display:
Hotkey #
1 <empty>
2 <Audio Processor> opens up the function block selection
Hotkey # Hotkey # (after pressing <Shift>)
1 <Input> <Level Magic>
2 <Phase Rotator> <FM Conditioner>
3 <Spectral Signature> <empty>
4 <Fail Over> <empty>
5 <De-Esser> <empty>
6 <Dynamics> <empty>
7 <Level Magic> <empty>
8 <Voice Over> <Output>
<ESC> back to operating display
3 <empty>
4 <EBU R 128> opens the loudness meter display
Hotkey #
1 <Input>
2 <Fail Over>
3 <Spectral Signature>
4 <Equalizer>
5 <Dynamics>
6 <Voice Over>
7 <Level Magic>
8 <Output>
<ESC> returns to the upper operating display
5 <empty>
6 <empty>
7 <empty>
8 <empty>
<ESC> returns to the main operating display
