junger D*AP4 FLX - Technical Data - Optional Interface Modules - Pin Assignment

D*AP4
80
Technical Data - Optional Interface Modules – pin assignment
4x analog I/O [O_DAP_ADDA_a] 4x AES I/O [O_DAP_AES_a] 8x analog out [O_DAP_8DA_a]
connector:
4 x analog I/O
female 25-pin D-Sub
1 OUT-4 +
2 GND
3 OUT-3 -
4 OUT-2 +
5 GND
6 OUT-1 -
7 IN-4 +
8 GND
9 IN-3 -
10 IN-2 +
11 GND
12 IN-1 -
13
14 OUT-4 -
15 OUT-3 +
16 GND
17 OUT-2 -
18 Out-1 +
19 GND
20 IN-4 -
21 IN-3 +
22 GND
23 IN-2 -
24 IN-1 +
25 GND
connector:
4x AES I/O
female 25-pin D-Sub
1 OUT-4 +
2 GND
3 OUT-3 -
4 OUT-2 +
5 GND
6 OUT-1 -
7 IN-4 +
8 GND
9 IN-3 -
10 IN-2 +
11 GND
12 IN-1 -
13
14 OUT-4 -
15 OUT-3 +
16 GND
17 OUT-2 -
18 OUT-1 +
19 GND
20 IN-4 -
21 IN-3 +
22 GND
23 IN-2 -
24 IN-1 +
25 GND
connector:
8 x analog out
female 25-pin D-Sub
1 OUT-8 +
2 GND
3 OUT-7 -
4 OUT-6 +
5 GND
6 OUT-5 -
7 OUT-4 +
8 GND
9 OUT-3 -
10 OUT-2 +
11 GND
12 OUT-1 -
13
14 OUT-8 -
15 OUT-7 +
16 GND
17 OUT-6 -
18 OUT-5 +
19 GND
20 OUT-4 -
21 OUT-3 +
22 GND
23 OUT-2 -
24 OUT-1 +
25 GND
