Technical Data – Option Board Audio-over-IP DANTE™ I/O [O_DAP_DANTE_a]
Standards Audio-over-IP by Dante™ Digital Audio Networking Standard
Audio 24bits, transparent forwarding of PCM and compressed audio
Audio Sample Rate 44.1, 48, 88.2, 96kHz
Inputs and Outputs 2 x Gigabit Ethernet RJ45 connectors (100M/1Gbit),
primary and secondary port
Inputs Processable by D*AP8: 16 channels @ 44.1, 48kHz
Processable by D*AP4: 8 channels @ 44.1, 48, 88.2, 96kHz
Outputs Processable by D*AP8: 16 channels @ 44.1, 48kHz
Processable by D*AP4: 8 channels @ 44.1, 48, 88.2, 96kHz
General Features
• AES67 compliant (when available)
• Network master-sync can be provided by D*AP device
• Master-sync capable (for D*AP device)
• Non-audio detection for input channels
• Glitch-free Dante™ audio redundancy using dual Ethernet
networks
