Technical Data – Option Board Analog I/O [O_DAP_ADDA_a]
Audio 24bit sigma-delta A/D-converter, 24bit D/A-converter
Audio Channels 4 input channels, 4 output channels
Audio Sample Rate 44.1, 48, 88.2, 96kHz
4 channels
Connector type D-Sub25 connector female, same for outputs
Input Level (max.)
(0dBFS equiv.)
0 … 24dBu, adjustable in 0.5dB steps
Impedance 20kOhm (typ.), differential
THD+N -93dB @ 0dBFS = 15dBu, 1kHz
Dynamic range > 110dB (RMS)
Crosstalk attenuation > 93dB @ 0dBFS = 15dBu, 1kHz
Analog Inputs
CMRR > 71dB @ 0dBFS = 15dBu, 1kHz
Frequency response 20Hz … 22kHz (< ±0.1dB) @ 48kHz
20Hz … 43kHz (< ±0.1dB) @ 96kHz
4 channels
Connector type D-Sub25 connector female, same for inputs
Output Level (max.)
(0dBFS equiv.)
0 … 24dBu, adjustable in 0.5dB steps
Impedance 50Ohm (typ.), differential
THD+N -91dB @ 0dBFS = 15dBu, 1kHz
Dynamic range > 103dB (RMS)
Crosstalk attenuation > 103dB @ 0dBFS = 15dBu, 1kHz
Analog Outputs
Frequency response 20Hz … 22kHz (< ±0.3dB) @ 48kHz
20Hz … 43kHz (< ±0.3dB) @ 96kHz
General Features
• Power fail relay bypass between inputs and outputs
• Balanced analog inputs and outputs
• Electrical isolation between inputs, outputs and device
