junger D*AP4 FLX - Technical Data - Option Board Analog out [O_Dap_8 Da_A]

D*AP4
74
Jitter tolerance > 0.7UI (Alignment)
Impedance 75Ohm
Output voltage 0.8Vpp (typ.)
Return loss > 15dB, 5 … 1485MHz
> 10dB, 1485 … 2970MHz
BNC Output
Output jitter < 0.2UI (Alignment), < 0.5UI (Timing)
Audio Latency Input to Output Embedder and de-embedder combined
HD, 3G < 0.6ms
SD typ. 1.5ms (< 2 ms)
General Features
• Power fail relay bypass (may be activated via GUI)
• Lip-Sync compensation for processed and non-processed audio
signals
• Dedicated routing for non-processed channels, all channels
(max. 16) can be routed to/from the device or looped through
• Test pattern generator
• Master-sync capable
• ITU-R BT.1685 / ARIB STD-B39 metadata support
Technical Data – Option Board Analog Out [O_DAP_8DA_a]
Audio 24bit D/A-converter
Audio Channels 8 output channels (e.g. for speakers)
Audio Sample Rate 44.1, 48, 88.2, 96kHz
8 channels
Connector type D-Sub25 connector female
Output Level (max.)
(0dBFS equiv.)
0 … 24dBu, adjustable in 0.5dB steps
Impedance 50Ohm (typ.), differential
THD+N -91dB @ 0dBFS = 15dBu, 1kHz
Dynamic range > 103dB (RMS)
Crosstalk attenuation > 103dB @ 0dBFS = 15dBu, 1kHz
Analog Outputs
Frequency response 20Hz … 22kHz (< ±0.3dB) @ 48kHz
20Hz … 43kHz (< ±0.3dB) @ 96kHz
General Features
• Power fail glitch prevention
• Balanced analog outputs
• Electrical isolation between outputs and device
