Juniper EX2200 Series User Manual

• Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 88
• Rack-Mounting and Cabinet-Mounting Warnings on page 167
Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet
You can mount an EX2200 switch except the EX2200-C switch model in a rack or cabinet
such that the switch is recessed inside the rack from the rack front by 2 inches. You can
use the 2-in.-recess front brackets provided in the separately orderable four-post
rack-mount kit to mount the switch in a recessed position.
Reasons that you might want to mount the switch in a recessed position include:
•
You are mounting the switch in a cabinet and the cabinet doors will not close completely
unless the switch is recessed.
•
The switch you are mounting has transceivers installed in the uplink ports—the
transceivers in the uplink ports protrude from the front of the switch.
To mount the switch in a recessed position on four posts, follow the instructions in
“Mounting an EX2200 Switch on Four Posts of a Rack or Cabinet” on page 84. To mount
the switch in a recessed position on two posts, follow the instructions in “Mounting an
EX2200 Switch on Two Posts of a Rack or Cabinet” on page 81.
Related
Documentation
Connecting Earth Ground to an EX Series Switch on page 103•
• Rack-Mounting and Cabinet-Mounting Warnings on page 167
Mounting an EX2200 Switch on a Wall
This topic describes the process of mounting an EX2200 switch on a wall.
1.
Mounting an EX2200 Switch Except the EX2200-C Model on a Wall on page 88
2.
Mounting an EX2200-C Switch on a Wall on page 91
Mounting an EX2200 Switch Except the EX2200-C Model on a Wall
You can mount an EX2200 switch on a wall by using the separately orderable wall-mount
kit.
WARNING:
When mounting an EX2200 switch chassis in a vertical position, orient the
front panel of the chassis downward to ensure proper airflow and meet
safety requirements in the event of a fire.
•
•
When wall mounting Power over Ethernet (PoE) models (EX2200-24P
and EX2200-48P), install the wall-mount baffle above the units to reduce
the risk of objects or substancesfallinginto the air exhaustor power supply,
which could cause a fire.
Copyright © 2011, Juniper Networks, Inc.88
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Series Specifications

General

Product Series	EX2200 Series
Operating Temperature	32° to 104° F (0° to 40° C)
Ports	24 or 48 10/100/1000 Ethernet ports, 4 SFP uplink ports
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
JUNOS Software	JUNOS Software
Layer 2 Features	VLAN
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Management	CLI, SNMP
Humidity	5% to 90% non-condensing
