Juniper EX2200 Series User Manual

Table 1: EX2200 Switch Models
First Junos OS
Release
Maximum PoE
Power Available
Ports in Which PoE Is
AvailableAccess PortsModel
11.3R1––12 Gigabit EthernetEX2200-C-12T-2G
11.3R1100 WAll 12 ports12 Gigabit EthernetEX2200-C-12P-2G
10.1R1––24 Gigabit EthernetEX2200-24T-4G
10.1R1405 WAll 24 ports24 Gigabit EthernetEX2200-24P-4G
11.3R1––24 Gigabit EthernetEX2200-24T-4G-DC
10.1R1––48 Gigabit EthernetEX2200-48T-4G
10.1R1405 WAll 48 ports48 Gigabit EthernetEX2200-48P-4G
Related
Documentation
EX2200 Switches Hardware Overview on page 3•
Chassis Physical Specifications for EX2200 Switches
The EX2200 switch chassis is a rigid sheet-metal structure that houses the hardware
components. Table 2 on page 9 summarizes the physical specifications of the EX2200
switch chassis.
Table 2: Physical Specifications of the EX2200 Switch Chassis
EX2200-C ValueEX2200 ValueDescription
1.75 in. (4.4 cm)1.75 in. (4.45 cm)Chassis height
•
10.6 in. (26.92 cm)
•
19 in. (48.26 cm) with mounting brackets
•
17.5 in. (44.5 cm)
•
19 in. (48.2 cm) with mounting brackets
attached
Chassis width
•
EX2200-C-12T: 9.0 in. (22.8 cm)
•
EX2200-C-12P: 9.4 in. (23.8 cm)
10.5 in. (26.7 cm)Chassis depth
•
EX2200-C-12T: 4.6 lb (2.1 kg)
•
EX2200-C-12P: 6.4 lb (2.9 kg)
•
EX2200-24T: 6 lb (2.7 kg)
•
EX2200-24P: 8 lb (3.6 kg)
•
EX2200-24T-DC: 6 lb (2.7 kg)
•
EX2200-48T: 8 lb (3.6 kg)
•
EX2200-48P: 10 lb (4.5 kg)
Weight
Related
Documentation
Rack Requirements for EX2200 Switches on page 57•
• Cabinet Requirements for EX2200 Switches on page 58
9Copyright © 2011, Juniper Networks, Inc.
Chapter 1: EX2200 Switch Overview

Juniper EX2200 Series Specifications

General

Product Series	EX2200 Series
Operating Temperature	32° to 104° F (0° to 40° C)
Ports	24 or 48 10/100/1000 Ethernet ports, 4 SFP uplink ports
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
JUNOS Software	JUNOS Software
Layer 2 Features	VLAN
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Management	CLI, SNMP
Humidity	5% to 90% non-condensing
