Figure 26: Attaching a Cable Guard to an EX2200-C Switch
g021161
5. (Optional) Attach the standard cable lock to the security slots on the both sides of
the switch
a. Rope the cable to a desk or a rack and set the lock to unlocked position.
b. Insert the lock into one of the security slot on your chassis and set the lock to the
locked position. See Figure 27 on page 81.
Figure 27: Securing the EX2200-C Switch Using Security Slots
g021160
Security slot
Security cable
Related
Documentation
Connecting AC Power to an EX2200 Switch on page 109•
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 129
• Wall-Mounting Warnings for EX2200 Switches on page 171
Mounting an EX2200 Switch on Two Posts of a Rack or Cabinet
You can mount an EX2200 switch on two posts of a 19-in. rack or cabinet by using the
mounting brackets provided with the switch. (The remainder of this topic uses “rack” to
mean “rack or cabinet”.)
81Copyright © 2011, Juniper Networks, Inc.
Chapter 8: Installing the Switch

Juniper EX2200 Series Specifications

General

Product Series	EX2200 Series
Operating Temperature	32° to 104° F (0° to 40° C)
Ports	24 or 48 10/100/1000 Ethernet ports, 4 SFP uplink ports
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
JUNOS Software	JUNOS Software
Layer 2 Features	VLAN
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Management	CLI, SNMP
Humidity	5% to 90% non-condensing
