Table 25: Parts List for EX2200 Switches (continued)
QuantityComponent
1RJ-45 cable and RJ-45 to DB-9 serial port adapter
-Cable guard and 3 number-8 Phillips truss-head screws (EX2200-C models only and separately orderable)
1Quick Start installation instructions
1Juniper Networks Product Warranty
1End User License Agreement
NOTE: You must provide mounting screws that are appropriate for your rack
or cabinet to mount the chassis on a rack or a cabinet.
Related
Documentation
Unpacking an EX2200 Switch on page 72•
• EX2200 Switches Hardware Overview on page 3
Mounting an EX2200 Switch
Table 26 on page 74 lists the methods you can use to mount an EX2200 switch.
Table 26: EX2200 Switch Mounting Methods
CommentsSwitch ModelMounting Method
On a desk or other level surface by using rubber feet provided with
the switch
•
EX2200
•
EX2200-C
Desk or other level surface
(using rubber feet)
On or under a desk or other level surface by using screwsEX2200-CDesk or other level surface
(using screws)
On two posts in a 19-in. rack or cabinet by using the mounting
brackets.
•
EX2200
•
EX2200-C
Two-post rack or cabinet
•
On four posts in a 19-in. rack or cabinet by using the separately
orderable four-post rack-mount kit
•
On two posts in a 19-in. rack or cabinet by using the two post
rack mounting brackets.
•
EX2200
•
EX2200-C
Four-post rack or cabinet
In a position recessed 2 in. from the front of a 19-in. rack or cabinet
by using the 2-in.-recess front brackets in the separately orderable
four-postrack-mount kit. You can mount the switch in this recessed
position on two-post or four-post racks and cabinets
EX2200Recessed position
Copyright © 2011, Juniper Networks, Inc.74
Complete Hardware Guide for EX2200 Ethernet Switches
