Stop bits—1
DCD state—Disregard
To connect and configure the switch from the console using the CLI:
1. Connect the console port to a laptop or PC using the RJ-45 to DB-9 serial port adapter.
The RJ-45 cable and RJ-45 to DB-9 serial port adapter are supplied with the switch.
For the location of the console port on different EX Series switches:
See “EX2200 Switches Hardware Overview” on page 3.
See Rear Panel of an EX3200 Switch.
See Rear Panel of an EX3300 Switch.
See Rear Panel of an EX4200 Switch.
See Front Panel of an EX4500 Switch.
See Switch Fabric and Routing Engine (SRE) Module in an EX6200 Switch.
See Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch.
See Routing Engine (RE) Module in an EX8216 Switch.
NOTE: In EX2200-C switch models, you can also use Mini-USB Type-B
console port to connect to a laptop or PC. See “Connecting an EX Series
Switch to a Management Console” on page 115.
2. At the Junos OS shell prompt root%, type ezsetup.
3. Enter the hostname. This is optional.
4. Enter the root password you plan to use for this device. You are prompted to re-enter
the root password.
5. Enter yes to enable services like Telnet and SSH. By default, Telnet is not enabled and
SSH is enabled.
NOTE: When Telnet is enabled, you will not be able to log in to an EX
Series switch through Telnet using root credentials. Root login is allowed
only for SSH access.
6. Use the Management Options page to select the management scenario:
NOTE: OnEX4500, EX6200, and EX8200 switches, only the out-of-band
management option is available.
Copyright © 2011, Juniper Networks, Inc.130
Complete Hardware Guide for EX2200 Ethernet Switches
