PC to the device, use a combinaon of the RJ-45 to DB-9 socket adapter along with a USB to DB-9 plug
adapter.
Table 34 on page 97 provides the pinout informaon for the RJ-45 to DB-9 serial port adapter.
Table 34: RJ-45 to DB-9 Serial Port Adapter Pinout Informaon
RJ-45 pin Signal DB-9 pin Signal
1 RTS 8 CTS
2 DTR 6 DSR
3 TxD 2 RxD
4 GND 5 GND
6 RxD 3 TxD
7 DSR 4 DTR
8 CTS 7 RTS
EX2300 Virtual Chassis
IN THIS SECTION
Planning EX2300 Virtual Chassis | 98
Understanding EX2300 Virtual Chassis Hardware Conguraon | 98
97
