Juniper EX2300 Series Hardware Guide

Mounng an EX2300 Switch in a Recessed Posion in a Rack or Cabinet
You can mount an EX2300 switch except the EX2300-C switch model on two posts or four posts of a
rack or cabinet such that the switch is recessed inside the rack from the rack front by 2 inches. You can
use the 2-in.-recess front-mounng brackets provided in the separately orderable four-post rack-mount
kit to mount the switch in a recessed posion.
Reasons that you might want to mount the switch in a recessed posion include:
• You are mounng the switch in a cabinet and the cabinet doors do not close completely unless the
switch is recessed.
• The switch you are mounng has transceivers installed in the uplink ports—the transceivers in the
uplink ports protrude from the front of the switch.
To mount the switch in a recessed posion on four posts, follow the instrucons in "Mounng an
EX2300 Switch on Four Posts of a Rack or Cabinet" on page 116. To mount the switch in a recessed
posion on two posts, follow the instrucons in "Mounng an EX2300 Switch on Two Posts of a Rack or
Cabinet" on page 113.
Connecng the EX2300 to Power
IN THIS SECTION
Connect Earth Ground to an EX Series Switch | 132
Connecng AC Power to an EX2300 Switch | 141
Connecng DC Power to an EX2300 Switch | 144
Connect Earth Ground to an EX Series Switch
IN THIS SECTION
Parts and Tools Required for Connecng an EX Series Switch to Earth Ground | 133
132

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
