Juniper EX2300 Series Hardware Guide

Unpacking and Mounng the EX2300 Switch
IN THIS SECTION
Unpacking an EX2300 Switch | 101
Parts Inventory (Packing List) for an EX2300 Switch | 102
Register Products—Mandatory to Validate SLAs | 103
Installing and Connecng an EX2300 Switch | 104
Mounng an EX2300 Switch | 105
Mounng an EX2300 Switch on a Desk or Other Level Surface | 106
Mounng an EX2300-C Switch Under a Desk or Other Level Surface by Using Screws | 108
Mounng an EX2300 Switch on Two Posts of a Rack or Cabinet | 113
Mounng an EX2300 Switch on Four Posts of a Rack or Cabinet | 116
Mounng an EX2300 Switch on a Wall | 119
Mounng an EX2300-C Switch on or Under a Surface Made of Ferrous Material | 127
Mounng an EX2300 Switch in a Recessed Posion in a Rack or Cabinet | 132
Unpacking an EX2300 Switch
EX2300 switches are shipped in a cardboard carton, secured with foam packing material. The carton
also contains an accessory box.
CAUTION: EX2300 switches are maximally protected inside the shipping carton. Do
not unpack the switches unl you are ready to begin installaon.
To unpack the switch:
1. Move the shipping carton to a staging area as close to the installaon site as possible, but where you
have enough room to remove the system components.
2. Posion the carton so that the arrows point up.
3. Open the top aps on the shipping carton.
4. Remove the accessory box and verify the contents in it against the parts inventory on the label
aached to the carton.
101

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
