Configuring Service Chaining Using VLANs
You can achieve service chaining using VLANs.
•
Ensure that connectivity to the host is not lost during the configuration process.
To configure service chaining:
1. Create a VLAN. Use one of the following commands:
•
Create a VLAN without a VLAN ID. You can add only access ports to this VLAN:
set host-os vlans vlan-name vlan-id none
•
Create a VLAN with a VLAN ID:
set host-os vlans vlan-name vlan-id vlan-id
•
Create a VLAN using a list of VLAN IDs:
set host-os vlans vlan-name vlan-id-list vlan-id range | comma-separated list
2. Attach an interface on the VNF to the VLAN:
set virtual-network-functions vnf-name interfaces ethx mapping vlan mode [access|trunk]
set virtual-network-functions vnf-name interfaces ethx mapping vlan members list
3. Attach a native VLAN ID to the VNF interface:
set virtual-network-functions vnf-name interfaces ethx mapping vlan native-vlan-id vlan-id
