Docu-No.: 0590020601-EN Rev. 1.6.0 Page 105
Appendix 5
LWF PSR Map 5.7
45 REFILL_BP_IN • Refill bypass input status
46 VOL_MODE_IN • Volumetric input status
47 EXTERN_IN • Extern (local) input status
48 DIRECT_IN • Direct (ratio) input status
49 EXT_AL_IN • External alarm input status
51 GEAR_SW_OUT • Hi (Lo) gear switch output enabled
52 BLOWOFF_OUT • Filter blowoff function set
64 DISP_PRESENT • KCM/KD internal display present
65 CPU_INIT_CPL • CPU initialization complete
66 MASS_MODE • Unit in Grav mode
67 CALIB • Currently running an auto calibrate
routine
68 PERT • Unit in PERT condition
69 REFILL • Feeder is refilling by automatic
means
70 REF_TIMEOUT • Refill timer has expired
75 LOADER_FULL( • Loader full input to control
76 LOADING • Loader motor is running
77 LOAD_ENA • Loader is enabled to run
PSR(Process number) Description
Table page 2 of 2
