K-TRON K-Vision - Stepper Motor Programming Table

Docu-No.: 0590020601-EN Rev. 1.6.0 Page 43
Programming Reference 1
Machine setup menu 1.7
1.7.10 Stepper motor programming table
• Stepper motor mounted optical encoder provides 400 pulses per
revolution-quadrature.
• For BSP150-S, use a gear reduction of 2.00.
• This list may change. Review stepper motor label before selecting
stepper drive and programming.
Feeder Type Max
Motor
RPM
Maximum
Power
Setting-W
Required Stepper Drive
BSP100
60 49
0000001430
0000005987
BSP135
60 194
0000004568
0000005987
BSP150-S
120** 194
0000004568
0000005987
KM-T12
150 43
0000005987
0000001430
