Docu-No.: 0590020601-EN Rev. 1.6.0 Page 99
Appendix 5
Status tables 5.4
5.4.5 SFT status table
This table shows the table of the possible Status displayed in the scale
menu at the variable SFT Status 1.6.2.
Example:
0183= group mode, group leader, filter on, weight conversion
complete.
Fig. 5.10 SFT hex codes
Bit Function Hex
Code
0 1 = Group mode 0001
1 1 = Group leader 0002
2 Not used 0004
3 1 = Continuous mode 0008
4 1 = Error received 0010
5 1 = Baud Rate range error 0020
6 1 = Not used 0040
7 1 = Filter on 0080
8 1 = Weight conversion complete 0100
9 1 = EEPROM read or write error 0200
10 1 = K-FFP (Fast Frequency Processor) error 0400
11 1 = Ft - temperature frequency out of range 0800
12 1 = Fw - weight frequency out of range 1000
13 1 = Weight window range error 2000
14 1 = Temperature window range error 4000
15 1 = General alarm 8000
0000 0001 1000 0011
15
0
0 1 8 3
Hex
Bits
