5 Appendix
5.8 LWF ASR Map
Page 106 Docu-No.: 0590020601-EN Rev. 1.6.0
5.8 LWF ASR Map
See section 4.2 for alarm specifics.
ASR(Alarm number) Description
00 HARDWARE
ERROR
• KCM Hardware error. EEPROM
data is corrupt. For example, this
message will occur after updating or
changing firmware on the KCM.
01 KPROM MEM
FAIL
• The K-PROM cannot be accessed
by the KCM CPU.
02
KPROM*KGR*FAIL
• Checksum error in kgr file area.
03 POWER GLITCH • Power dip detected. CPU did not
reset.
05 INT CHAN FAIL • Internal channel has failed to
communicate between the CPU and
drive boards. (also SFTs and HCU)
06 WT PROC
FAILURE
• SFT(s) failed.
• Serial communication to the load cell
interrupted.
• f = SFT internal failure. communica-
tion OK.
• t = No communication from the SFT
to the controller board.
• ?= Not valid answer from SFT.
07
INCORRECTNUM.S
FT
• Number of SFTs found during
polling does not equal that required.
08 BAD SFT
STATUS
• SFT is showing an incorrect status.
09 NO MDU FOUND • The KCM CPU did not find a motor
drive on the internal channel on
power-up.
10 MOTOR ALARM • The KCM CPU lost the motor drive
on the internal channel while in
operation.
Table page 1 of 6
