K-TRON K-Vision User Manual

Docu-No.: 0590020601-EN Rev. 1.6.0 Page 49
Programming Reference 1
I/O Menu 1.8
1.8.1 Digital input sub-menu
Parameter
Definition
DIG IN
Digital Input
Selection of the desired bit input of the KCM for programming. Select
any of the following inputs: CPU1-CPU4, MDU_IN1, MDU_IN2,
Spare 1, Spare 2, Ext _In1 - Ext _In8.
Note:
For Ext In function to work, Modbus I-O must be configured first and
the external I-O module (e.g.WAGO) connected via K-Port 2.
Input Range: See list
FUNCTION
Digital Input Function
Input function of the selected output no. [1-24].
Selection: None, Start*, Stop*, Interlock, Run Enable, ALS Input, Ack
Alarm*, Clr Alarm*, Start/Stop, Vol Mode, Loc/Ext, Rat/Dir, Ext
Alarm, Total Clr*, Data Lock, Empty*, Ref Bypass, Ref Cmd*, Calib*,
Loader Lvl, Loader Ena, Jog, ScrFill
Input Range: See list
Default: CPU_In_1 = Start, CPU_In_2 = Stop, CPU_In_3 = ALS
Input.
Note:
• Ref Cmd is only functional if refill is enabled and net weight is <
Refill Max weight. Ref Bypass is only functional if the Refill is
Enabled.
• If refill is active and running, initiating a Refill Command input will
terminate the refill. If the refill is not active, initiating the Refill
Command input will cause the Refill cycle to begin as stated under
the prior conditions.
Note; If feeder is running then:
• Interlock requires no Start command upon release of Interlock for
the feeder to re-start
• Run Enable requires a Start command upon release of Run
Enable to re-start the feeder
STATE
Digital Input State
Displaying the actual status of the selected digital input.
Input range: Display only (Off or 0 = not active, On or 1 = active)
POLARITY
Polarity
The selected digital input changes the function from e.g NO to NC.
Selections are:
Input range: Normal or Inverse
Default: Normal
